- Measurement of RMS voltages and currents at 128 times per cycle and stored every second
- Measurement of VA, W and var power values (total and per phase) stored every second
- Measurement of VAh, Wh and varh energy values (total and per phase) per second with source/load indication
- Calculation of the cos f Displacement Power Factor (DPF) and the Power Factor (PF) stored every second
- Calculation of Total Harmonic Distortion (THD)
- Measurement, calculation and display of the harmonics up to the 50th order for 50/60 Hz and 7th order for 400Hz
- Measurement of the DC quantities (RMS calculation)
- Electrical network quantities are stored on a removable SD-Card
- Automatic recognition of the connected current sensors
- DataView software for configuration, data retrieval and real-time viewing of measurements with a PC
- Compact and rugged case
- Versatile communication interface choices built in (USB, Ethernet, Bluetooth)
>
Each Unit Includes
- Small Classic Tool Bag
- Three MA193-10-BK Sensors
- 5 USB Cable
- Four Black Test Leads and Alligator Clips
- Power cord
- 12 Color-coded ID Markers
- Multifix Mounting System
- Safety Card for the PEL
- Sensor Compliance Sheet
- 2 GB SD Card with USB SD Card Reader
- USB Stick with Dataview
- Quick Start User Guide
- User Manual
