- Enables successful thermographic inspection of high-voltage/current electrical environments
- Minimizes inspection time/cost and reduces the chance of injuries compared to other inspection methods
- Stainless steel frame with high corrosion resistance and durability in harsh environments
- Hinged flip open cover with integrated thumb screw
- Broadband Calcium Fluoride (CaF2) crystal suitable for Visual, Thermal and Fusion inspections
- Crystal insert diameter 3.74 (95mm)
- Convenient, easy to use design. PIRma-Lock™ locking ring.
- Simple 3-step installation with no screw hole drilling required. Window size matches standard knockout punch.
- NEMA environmental rating Type 4/12 (outdoor/indoor)
- Limited Lifetime Warranty against manufacturer defects
