Fluke 717-1000G
Roll over image to zoom in
$1,070.00
Compact and high-accuracy pressure calibrator with 0.05% full-scale accuracy, designed for measuring and calibrating pressure and current up to 1000 psi.
Fluke 717 1000G Pressure Calibrator, 0 to 1000 psi, 0.05% Accuracy.
The Fluke 717 1000G Pressure Calibrator is a rugged, reliable, and easy-to-use pressure calibrator engineered for professionals in process control environments. Capable of measuring pressure up to 1000 psi (69 bar) with a remarkable 0.05% full-scale accuracy, it is ideal for calibrating transmitters, pressure switches, and I/P converters.
This calibrator also allows simultaneous pressure and current measurements, making it perfect for calibrating P/I instruments in the field or in the lab. Designed for both ease of use and portability, it includes intuitive controls and a compact form factor.
For those seeking a deeper understanding of pressure calibration applications, read our comprehensive article:
Pressure Calibrators Explained: How to Ensure Process Accuracy in Industrial Settings.
Key Features
-
Pressure Range: 0 to 1000 psi (69 bar / 6894.8 kPa)
-
Accuracy: ±0.05% full scale
-
Current Measurement: Up to 24 mA with 0.015% accuracy and 0.001 mA resolution
-
24V Loop Power: Powers transmitters while measuring current
-
Pressure Switch Testing: Captures set, reset, and deadband values
-
Module Compatibility: Compatible with Fluke 700Pxx Pressure Modules to extend pressure capability up to 10,000 psi (700 bar)
-
Engineering Units: Select from 11 pressure units
-
Compact and Durable: Lightweight, field-ready, and compatible with Fluke\’s Toolpack magnetic hanging system
-
Certified Accuracy: Delivered with NIST-traceable calibration report and data
Looking for similar tools? Explore more in our General Pressure Calibrators section.
Why Choose the Fluke 717 1000G?
This model is part of Fluke’s trusted 717 Series and is highly regarded for its reliability, portability, and multifunctionality. Whether you\’re verifying a pressure transmitter or performing routine plant maintenance, the Fluke 717 1000G simplifies pressure calibration tasks without compromising on accuracy. Its dual measurement capability for pressure and current in a single tool sets it apart from traditional instruments.
What’s Included
-
Fluke 717 1000G Pressure Calibrator
-
Protective yellow holster with test lead storage
-
Test leads and alligator clips
-
Single 9V alkaline battery
-
Instruction sheet (multi-language)
-
NIST-traceable calibration certificate
Technical Specifications
| Parameter | Value |
|---|---|
| Pressure Range (Internal) | 0 to 1000 psi / 69 bar / 6894.8 kPa |
| Accuracy (Pressure) | ±0.05% full scale |
| Resolution | 0.1 psi / 1 mbar / 0.1 kPa |
| Current Measurement | 0 to 24 mA, 0.015% accuracy + 2 counts |
| Loop Power | 24V DC ±10% |
| Engineering Units | 11 selectable units |
| Temperature Range | -10°C to 55°C (Operating), -40°C to 60°C (Storage) |
| Display | 5-digit LCD |
| Battery Life | Approx. 20 hours |
| Weight | Approx. 600g (with holster) |
| Dimensions | 201 x 98 x 52 mm (7.93 x 3.86 x 2.06 in) |
| Safety | CSA C22.2 No. 1010.1:1992 compliant |
Applications
-
Pressure transmitter calibration
-
Switch testing and verification
-
Process instrumentation calibration
-
General industrial maintenance
-
On-site troubleshooting in power plants, refineries, and HVAC systems
Explore More
-
Browse our complete range of Pressure Calibrators
-
Learn best practices in: How to Calibrate a Pressure Transmitter Using a Loop Calibrator
