GW Instek GPT-9902A: Precision Programmable AC Power Source for Advanced Testing

Features and Specifications: GW Instek GPT-9902A

Product Overview:

The GW Instek GPT-9902A is a high-performance programmable AC power source designed for demanding applications in research, development, and manufacturing. With its advanced features and precise control, it provides a reliable and versatile solution for testing and powering electronic devices.

Features:

Wide Output Range: 0-300Vrms, 0-10Arms
High Power Output: 900VA
Low Output Impedance: <0.05Ω
High Output Stability: <0.05% + 5mV
Programmable Output: Voltage, current, frequency, and phase
Multiple Output Modes: AC, DC, and AC+DC
Harmonic Analysis Function: Up to 50th harmonic
Sequence Function: Up to 100 steps
Remote Control Interface: USB, RS-232, and GPIB

Output Voltage: 0-300Vrms, 0-10Arms
Output Frequency: 45Hz-1kHz
Output Impedance: <0.05Ω
Output Stability: <0.05% + 5mV
Harmonic Distortion: <0.5% (typical)
Power Factor: 0.99 (typical)
Display: 4.3\” TFT LCD
Dimensions: 430mm x 215mm x 133mm
Weight: 10kg

What\’s in the Box:

GW Instek GPT-9902A AC Power Source
Power Cord
USB Cable
RS-232 Cable
GPIB Cable
User Manual

Benefits:

Precise and Stable Output: Ensures accurate and reliable testing results.
Versatile Output Modes: Supports a wide range of applications, including AC, DC, and AC+DC testing.
Programmable Operation: Automates testing and simplifies complex sequences.
Harmonic Analysis Function: Provides detailed insights into harmonic content.
Remote Control Interface: Enables integration with automated test systems.

Enhanced Testing Capabilities: Enables precise and comprehensive testing of electronic devices.
Increased Efficiency: Automates testing and reduces manual intervention.
Improved Reliability: Ensures accurate and repeatable test results.
* Cost Savings: Eliminates the need for multiple power sources and reduces testing time.
