- Accuracy: 0.2% F.S., 1 LSD
- Selectable Units: lbf(ozf), kgf(gf) or Newtons
- Overload Capacity: 200% of F.S. (Overload indicator flashes beyond 110% of F.S.)
- Power: Rechargeable Ni-MH battery pack or AC adapter
- Battery Indicator: Indicates three charge states high, med, and low
- Memory: Non-volative, recall up to 1,000 data
- Setpoints: Programmable high/low setpoints w/ color-coded LEDs output signal
- Outputs: Outputs USB (virtual COM port), RS-232C, Digimatic and 2 VDC analog output
- Operating Temperature: 32 to 100 F (0 to 40 C)
- Warranty: 2 Years
- Electroluminescent display (ELD) is highly visible in dark locations
- USB (virtual COMport), RS-232C, Digimatic and Analog outputs
- Processes and transmits 2,000 data/sec
- Internal Ni-MH batteries or AC adapter
- Ergonomic design with non-slip grips, heavy duty metal construction
- Real time and peak mode (selectable)
- Overload capacity 200% F.S.
- Overload alarm and output signal
- Multi-langauge program menus: English, Spanish, French, Chinese, German, Italian, Korean, Japanese
- lbf, kgf, and N units are selectable
- Color-coded LED indicators and output signal for Go/No Go testing
- Export gauge memory or save continuous data to USBflash drives (ZTA Models only)
- Display force and displacement data with FA test stand (ZTA Models only)
- External switch display hold and clear
