Keysight 8764C/024: 5-Port Coaxial Switch for High-Frequency Applications

Keysight 8764C/024 5-Port Coaxial Switch, DC to 26.5 GHz

Product Overview:

The Keysight 8764C/024 is a high-performance 5-port coaxial switch designed for demanding RF and microwave applications. It offers exceptional switching speed, low insertion loss, and high isolation, making it ideal for use in test and measurement systems, signal routing, and antenna switching.

Features and Specifications:

Frequency Range: DC to 26.5 GHz
Insertion Loss: <0.5 dB (typical)
Isolation: >60 dB (typical)
Switching Speed: <100 ns
Power Handling: 200 W (CW)
Control Interface: USB, GPIB, LAN
Dimensions: 13.3\” x 8.5\” x 3.5\” (338 mm x 216 mm x 89 mm)

High Performance: Exceptional switching speed, low insertion loss, and high isolation ensure accurate and reliable signal routing.
Wide Frequency Range: Covers a wide range of frequencies from DC to 26.5 GHz, making it suitable for various applications.
Versatile Control: Supports multiple control interfaces (USB, GPIB, LAN) for easy integration into test systems.
Rugged Construction: Built to withstand harsh environments and ensure long-term reliability.

Enhanced Test Accuracy: High performance ensures accurate and reliable signal routing, improving test results.
Increased Efficiency: Fast switching speed and versatile control options streamline test processes and save time.
Broad Application Range: Wide frequency range and high power handling make it suitable for a wide range of applications.
* Long-Term Reliability: Rugged construction ensures durability and minimizes downtime.
