Keysight DSOX3014G: 4-Channel Digital Oscilloscope with WaveGen, 100 MHz, 4 Mpts, 5 GS/s
Roll over image to zoom in
$4.020
The Keysight DSOX3014G is a 4-channel, 100 MHz digital oscilloscope from the InfiniiVision 3000G X-Series, featuring a 5 GSa/s sampling rate, built-in function generator, protocol decoding, and an 8.5″ capacitive touchscreen. Ideal for embedded systems, R&D labs, and advanced waveform analysis.
Keysight DSOX3014G – Digital Oscilloscope (100 MHz / 4 Channels).
The Keysight DSOX3014G delivers exceptional performance, deep functionality, and user-friendly touchscreen control in a compact benchtop form. Designed for engineers working with embedded systems, power electronics, and digital communications, this 100 MHz oscilloscope features 4 analog channels, a sampling rate of 5 GSa/s, and 1,000,000 waveforms per second update rate, giving you high visibility into signal anomalies.
What sets it apart is its 7-in-1 multi-instrument capability, combining the functions of a digital oscilloscope, function generator, protocol analyzer, digital voltmeter, frequency counter, totalizer, and more. It comes pre-loaded with the D3000GENB embedded software package, enabling I2C, SPI, UART, RS232/485, and I2S protocol decoding—critical for today’s complex electronics.
💡 Learn how to apply this instrument in real-world scenarios:
👉 How to Use Oscilloscopes for Power Quality Analysis: A Practical Guide for Engineers and Technicians
👉 Top 5 Oscilloscopes for Engineers and Labs in 2025
Key Features:
-
Bandwidth: 100 MHz
-
Channels: 4 analog inputs
-
Sample Rate: 5 GSa/s
-
Memory Depth: 4 Mpts
-
Waveform Update Rate: 1,000,000 wfm/s
-
Display: 8.5″ capacitive multi-touch screen
-
Rise Time: 3.5 ns
-
Function Generator: Built-in 20 MHz ARB / waveform generator
-
Digital Voltmeter & Frequency Counter: 3-digit voltmeter and 8-digit counter
-
Protocol Decoding (Included): I2C, SPI, UART/RS232/485, I2S
-
Upgradable: Mixed signal (MSO) option available post-purchase
Included in Package:
-
Keysight DSOX3014G Oscilloscope
-
(4x) N2843A 500 MHz Passive Probes (10:1 attenuation)
-
D3000GENB Embedded Protocol Software Package
-
PathWave BenchVue Oscilloscope Software (BV0004B)
-
Factory 3-Year Warranty
-
Calibration Certificate (3-year interval)
-
Power Cord & Front Panel Overlay
-
Documentation CD (User, Service & Programmer’s Guides)
-
KeysightCare Technical Support
Technical Specifications:
| Specification | Value |
|---|---|
| Bandwidth | 100 MHz |
| Channels | 4 Analog |
| Sampling Rate | 5 GSa/s |
| Memory Depth | 4 Mpts (4096 kB) |
| Display Size | 8.5 inches |
| Rise Time | 3.5 ns |
| Logic Channels | 0 (MSO available separately) |
| Instrument Weight | 9.3 lbs (4.2 kg) |
| Dimensions (HxWxD) | 8″ x 15″ x 5.6″ |
| Warranty | 3 Years |
