RIGOL PHA2150: High-Precision Differential Probe for Demanding Measurements
Roll over image to zoom in
Features and Specifications: RIGOL PHA2150 High Voltage Differential Probe, 50X/500X, 200 MHz, PHA Series
Product Overview:
The RIGOL PHA2150 is a high-performance differential probe designed for precise measurements in high-voltage applications. With its wide bandwidth of 200 MHz and high voltage range of ±1500 V, it is ideal for testing power electronics, automotive systems, and other high-voltage circuits.
Features:
High Voltage Range: ±1500 V differential, ±750 V common mode
Wide Bandwidth: 200 MHz
High Input Impedance: 10 MΩ // 10 pF
Low Input Capacitance: 10 pF
Selectable Attenuation: 50X/500X
Ground Reference Compensation: Ensures accurate measurements even with floating ground
Auto Zero Function: Automatically compensates for probe offset
Overvoltage Protection: Protects the probe from accidental overloads
Compact and Lightweight: Easy to handle and transport
Specifications:
Voltage Range: ±1500 V differential, ±750 V common mode
Bandwidth: 200 MHz
Attenuation: 50X/500X
Input Impedance: 10 MΩ // 10 pF
Input Capacitance: 10 pF
Rise Time: 1.75 ns (50X), 3.5 ns (500X)
Accuracy: ±2% (50X), ±3% (500X)
Dimensions: 150 mm x 70 mm x 30 mm
Weight: 250 g
What’s in the Box:
RIGOL PHA2150 High Voltage Differential Probe
Grounding Lead
Calibration Certificate
User Manual
Benefits:
Accurate and Reliable Measurements: High voltage range and wide bandwidth ensure precise measurements in demanding applications.
Versatile and Convenient: Selectable attenuation and ground reference compensation provide flexibility for various testing scenarios.
Safe and Durable: Overvoltage protection and compact design ensure safety and longevity.
Enhanced Productivity: Auto zero function and easy-to-use interface streamline the measurement process.
Value to the Customer:
The RIGOL PHA2150 High Voltage Differential Probe empowers engineers and technicians with the tools they need to confidently and efficiently test high-voltage circuits. Its exceptional performance, versatility, and safety features make it an invaluable asset for any professional involved in power electronics, automotive, or other high-voltage applications.
Additional information
| Brand | RIGOL |
|---|
