Tektronix FCA3103: Precision Frequency Counter/Timer for Demanding Applications

Features and Specifications: Tektronix FCA3103 Frequency Counter/Timer

Product Overview:

The Tektronix FCA3103 is a high-performance frequency counter/timer designed for precise and reliable measurements in various applications. With its advanced features and exceptional accuracy, it empowers engineers and technicians to analyze and troubleshoot electronic systems effectively.

Features:

3-Channel Input: Simultaneously measure up to three signals with independent inputs.
3 GHz Frequency Range: Measure frequencies up to 3 GHz with high resolution.
50 ps Time Interval Resolution: Capture precise time intervals with exceptional accuracy.
12-Digit Display: Provides high-resolution readings for detailed analysis.
USB and GPIB Interfaces: Enable remote control and data transfer for automated testing and integration.
Intuitive User Interface: Simplifies operation and minimizes setup time.
Advanced Triggering Modes: Capture specific events and isolate signals of interest.
Statistical Analysis: Provides comprehensive data analysis capabilities, including mean, standard deviation, and min/max values.

Specifications:

Frequency Range: 1 Hz to 3 GHz
Time Interval Resolution: 50 ps
Display Resolution: 12 digits
Input Sensitivity: <10 mVrms
Input Impedance: 50 ohms
Trigger Level Range: -10 dBm to +10 dBm
Trigger Modes: Edge, Width, Time Interval, Burst
Interfaces: USB 2.0, GPIB

What\’s in the Box:

FCA3103 Frequency Counter/Timer
Power cord
USB cable
GPIB cable
User manual

Enhanced Accuracy: Precise measurements with 50 ps time interval resolution and 12-digit display.
Versatile Applications: Suitable for a wide range of applications, including telecommunications, aerospace, and electronics manufacturing.
Efficient Troubleshooting: Advanced triggering modes and statistical analysis capabilities simplify fault isolation and system optimization.
Automated Testing: USB and GPIB interfaces enable remote control and data transfer for automated testing and integration.
User-Friendly Operation: Intuitive user interface and comprehensive documentation ensure ease of use and minimal setup time.

Value Proposition:

The Tektronix FCA3103 Frequency Counter/Timer offers exceptional value by providing:

Precision and Reliability: Accurate and dependable measurements for critical applications.
Versatility and Efficiency: Supports multiple channels, wide frequency range, and advanced features for efficient troubleshooting and analysis.
Automation and Integration: Remote control and data transfer capabilities enhance productivity and streamline testing processes.
User-Centric Design: Intuitive interface and comprehensive documentation empower users to maximize the instrument\’s capabilities.
