Tektronix P5100A-PKG: 500 MHz Passive Probe for Precision Measurements

Features and Specifications

Tektronix P5100A-PKG Passive Probe, 500 MHz, 100X, 2.5 pF, 1 kV, CAT2, P-Series

Product Overview

The Tektronix P5100A-PKG is a high-performance passive probe designed for use with oscilloscopes. It offers a wide bandwidth of 500 MHz, a high input impedance of 100 MΩ, and a low input capacitance of 2.5 pF. This makes it ideal for probing high-speed signals in a variety of applications, including digital design, power electronics, and telecommunications.

Features

Bandwidth: 500 MHz
Input impedance: 100 MΩ
Input capacitance: 2.5 pF
Maximum input voltage: 1 kV
CAT II safety rating
P-Series compatibility

Specifications

Bandwidth: 500 MHz
Input impedance: 100 MΩ ±2%
Input capacitance: 2.5 pF ±0.5 pF
Maximum input voltage: 1 kV
CAT II safety rating: 600 V
Probe tip: 4 mm banana plug
Probe length: 1.2 m (4 ft)
Weight: 150 g (5.3 oz)

What\’s in the Box

Tektronix P5100A-PKG Passive Probe
Ground lead
Probe tip
Instruction manual

Benefits

High bandwidth for probing high-speed signals
High input impedance for minimizing loading effects
Low input capacitance for preserving signal integrity
High maximum input voltage for safe use in a variety of applications
CAT II safety rating for protection against electrical hazards
P-Series compatibility for use with a wide range of Tektronix oscilloscopes

Value

The Tektronix P5100A-PKG Passive Probe is a valuable tool for engineers and technicians who need to probe high-speed signals. It offers a combination of high performance, safety, and compatibility that makes it an ideal choice for a variety of applications.
