Tektronix P6243: Precision SMD Active Probe for High-Frequency Measurements
Roll over image to zoom in
$2.162
Tektronix P6243 Active Probe for SMDs: 1 GHz, 10X, Single-Ended TekProbe for precise measurements on surface-mount devices (SMDs), ensuring signal integrity and accurate analysis.
Features and Specifications
Tektronix P6243 Active Probe for SMDs, Single-Ended TekProbe, 1 GHz, 10X
Product Overview
The Tektronix P6243 is an active probe designed for probing small surface-mount devices (SMDs). It features a 1 GHz bandwidth and a 10X attenuation ratio, making it ideal for high-speed signal measurements. The P6243 also has a small form factor and a flexible probe tip, making it easy to use in tight spaces.
Features
1 GHz bandwidth
10X attenuation ratio
Small form factor
Flexible probe tip
Ground lead included
Specifications
Bandwidth: 1 GHz
Attenuation ratio: 10X
Input impedance: 1 MΩ // 10 pF
Output impedance: 50 Ω
Rise time: 350 ps
Maximum input voltage: ±10 V
Probe tip: Flexible, 0.5 mm diameter
Probe length: 12 inches
Weight: 2 ounces
What\’s in the Box
Tektronix P6243 Active Probe
Ground lead
User manual
Benefits
The Tektronix P6243 Active Probe is ideal for probing small surface-mount devices (SMDs).
Its 1 GHz bandwidth and 10X attenuation ratio make it suitable for high-speed signal measurements.
The small form factor and flexible probe tip make it easy to use in tight spaces.
* The P6243 is a valuable tool for engineers and technicians who need to probe SMDs.
Value
The Tektronix P6243 Active Probe is a high-quality probe that is built to last. It is a valuable tool for engineers and technicians who need to probe SMDs. The P6243 is backed by Tektronix\’s industry-leading warranty and support.
