Tektronix P7513A TriMode Differential Probe: Uncover High-Speed Signals with Precision
Roll over image to zoom in
$15.521
Tektronix P7513A TriMode Differential Probe: 13 GHz bandwidth, TekConnect interface, P7500 Series, differential, single-ended, and common mode measurements.
Features and Specifications: Tektronix P7513A TriMode Differential Probe, 13 GHz, TekConnect Interface, P7500 Series
Product Overview:
The Tektronix P7513A TriMode Differential Probe is a high-performance probe designed for use with oscilloscopes in the P7500 Series. It offers exceptional bandwidth, accuracy, and versatility, making it ideal for a wide range of applications, including high-speed digital design, power integrity analysis, and RF measurements.
Features:
TriMode Operation: Supports differential, single-ended, and common mode measurements, providing maximum flexibility.
13 GHz Bandwidth: Captures high-frequency signals with exceptional accuracy and detail.
TekConnect Interface: Ensures a secure and reliable connection to P7500 Series oscilloscopes.
High Input Impedance: Minimizes loading effects on the circuit under test.
Low Noise: Delivers clean and precise measurements, even in noisy environments.
Adjustable Attenuation: Allows for optimal signal scaling and measurement accuracy.
Compact and Lightweight: Facilitates easy handling and portability.
Specifications:
Bandwidth: 13 GHz
Input Impedance: 1 MΩ || 1 pF
Attenuation: 1x, 10x, 100x
Input Voltage Range: ±1.5 V (DC + AC peak)
Common Mode Rejection Ratio: >60 dB at 1 GHz
Rise Time: <25 ps
Probe Tip: Grounded, 1.5 mm diameter
What\’s in the Box:
P7513A TriMode Differential Probe
Grounding Lead
Probe Tip
Calibration Certificate
Benefits:
Enhanced Measurement Accuracy: High bandwidth and low noise ensure precise and reliable measurements.
Versatile Operation: TriMode operation allows for a wide range of measurement scenarios.
Simplified Setup: TekConnect interface provides a quick and easy connection to oscilloscopes.
Improved Productivity: Compact design and adjustable attenuation streamline the measurement process.
Exceptional Value: Delivers high performance and versatility at an affordable price.
Value to the Customer:
The Tektronix P7513A TriMode Differential Probe empowers engineers and technicians with a powerful tool for high-speed signal analysis. Its exceptional bandwidth, accuracy, and versatility make it an indispensable asset for a wide range of applications, enabling users to:
Accurately characterize high-speed digital signals
Analyze power integrity issues with precision
Perform RF measurements with confidence
* Enhance productivity and efficiency in their measurement tasks
