Teledyne LeCroy WAVESURFER 4054HD : 4-Channel, 500 MHz, 5 GS/s Oscilloscope for Precision Analysis
Roll over image to zoom in
$11.819
Teledyne LeCroy WAVESURFER 4054HD PROMO1 MSO Oscilloscope: 4-channel, 500 MHz bandwidth, 5 GS/s sample rate, 4000HD Series, advanced triggering and analysis capabilities for precise signal acquisition and analysis.
Teledyne LeCroy WAVESURFER 4054HD PROMO1 MSO Oscilloscope
Product Overview:
The Teledyne LeCroy WAVESURFER 4054HD Oscilloscope is a high-definition, mixed-signal oscilloscope designed for demanding applications in electronics, telecommunications, and advanced research and development. With its 12-bit HD4096 technology, 500 MHz bandwidth, and 5 GS/s sampling rate, it offers industry-leading visibility and analysis for intricate signals and systems.
Ideal for:
-
Signal integrity and timing analysis
-
Debugging embedded systems and high-speed serial data
-
Power integrity and transient detection
✅ Explore More Oscilloscopes »
Key Features:
-
12-bit vertical resolution with HD4096 technology – always on
-
Bandwidth: 500 MHz
-
Channels: 4
-
Sample Rate: 5 GS/s per channel
-
Memory Depth: 25 Mpts
-
Large Display: 12.1” capacitive touch screen for intuitive control
-
Low Noise Floor and high signal fidelity for detailed waveform visibility
Technical Specifications:
| Attribute | Value |
|---|---|
| Bandwidth | 500 MHz |
| Channels | 4 |
| Sample Rate | 5 GS/s |
| Memory | 25 Mpts |
| Rise Time | 700 ps |
| Vertical Resolution | 12 bits |
| Screen Size | 12.1 in |
| Warranty | 3 Years |
| Origin | China |
📘 Related Article:
How PC-Based Oscilloscopes Are Transforming Modern Engineering Labs:
Included Accessories (What’s in the Box):
-
(4) 10:1 Passive Probes
-
Micro SD Card (Installed) & Adapter
-
Protective Front Cover
-
Getting Started Guide
-
NIST Traceable Calibration Certificate
-
Power Cable
Why Choose the WAVESURFER 4054HD?
The WAVESURFER 4054HD empowers engineers and technicians with ultra-clear waveform visibility, precise triggering, deep memory, and an intuitive interface. It is the ideal solution for high-performance mixed-signal analysis, making it invaluable for professionals working on complex embedded systems, power electronics, or RF signals.
