Vitrek V73: The Ultimate Hipot Tester for AC/DC, IR, and Low Resistance Testing
Roll over image to zoom in
$1.139
Vitrek V73 Hipot Tester: AC/DC, IR, Low Resistance, 20-5000 VDC, Color Touch LCD, V7X Series
Vitrek V73 Hipot Tester, AC/DC, IR, Low Resistance, 20-5000 VDC, Color Touch LCD, V7X Series
Product Overview:
The Vitrek V73 Hipot Tester is a versatile and advanced testing instrument designed to perform a wide range of electrical safety tests on electrical equipment, components, and materials. It combines AC/DC hipot testing, insulation resistance (IR) testing, and low resistance testing capabilities in a single, compact unit.
Combining AC/DC hipot, insulation resistance (IR), and low resistance testing into one unit, it offers unmatched flexibility and ease of use, all in a rugged, fan-free chassis ideal for lab or production use.
With a 4.3\” color touchscreen, intuitive interface, and ultra-fast test capability (100ms min), the V73 simplifies electrical safety testing while delivering high accuracy and repeatability.
🔌 Browse all Electrical Test Instruments for Compliance & Safety
Key Features & Benefits
-
AC/DC/IR 3-in-1 Safety Testing
-
Up to 5kV AC/DC output, with 20 mA max source current
-
Continuously variable IR test voltage: 20–5000 V
-
Maximum IR range: Up to 450 GΩ
-
Multi-Mode IR Testing: Steady and Rising Pass
-
Arc Detection and 100 nano-Amp leakage resolution
-
Fast test cycle – minimum 100 ms
-
Touchscreen Display: 4.3” color panel for easy operation
-
Low Cost of Ownership: 2-year calibration interval
-
CE & UL Certified for safety compliance
-
Interfaces: USB, RS-232, Digital I/O
🛠️ Explore more Hipot Testers in our Safety Testing Category
Applications
The Vitrek V73 is ideal for use in:
-
Production line safety testing
-
R&D labs and QA environments
-
Testing of medical devices, automotive electronics, consumer appliances, and industrial controls
-
Ensuring compliance with UL, CSA, and IEC safety standards
Technical Specifications
| Category | Specification |
|---|---|
| Test Types | AC Hipot, DC Hipot, Insulation Resistance |
| Max AC/DC Test Voltage | 5,000 V |
| Min AC Test Voltage | 10 V |
| Max AC Trip Current | 20 mA |
| Max DC Trip Current | 10 mA |
| IR Test Voltages | 10 V – 5000 V (multiple preset steps) |
| Max Insulation Resistance | 450 GΩ |
| Arc Detection | Yes |
| Display | 4.3\” Color Touch LCD |
| Interfaces | USB 2.0, RS-232, Digital I/O |
| Data Logging | Yes |
| Storage | Internal Memory |
| Power Supply | 120V / 220V Universal Input |
| Weight | 12 lbs (5.44 kg) |
| Dimensions (H x W x L) | 133 mm x 240 mm x 280 mm |
| Safety Approvals | CE, UL |
| Warranty | 2 Years |
| Calibration | NIST Traceable Certificate Included |
🧰 Looking for Calibration Equipment? Browse Our Calibration Instruments
What’s in the Box
-
Alligator test leads (TL-209)
-
Power cord
-
Operator\’s manual (CD)
-
QT Pro V Utility Software + Evaluation version test automation software
-
ANSI/NCSL Z540 NIST Traceable Calibration Certificate
-
2-Year Accuracy Spec & Recommended Calibration Interval
Customer Value Proposition
The Vitrek V73 Hipot Tester delivers high-performance safety testing with industry-grade precision, intuitive operation, and long-term reliability. It\’s ideal for customers looking to:
-
Streamline safety compliance testing
-
Improve product quality and reliability
-
Reduce test time and equipment maintenance costs
-
Ensure full compliance with international standards
📦 Explore More Pressure Measurement for Quality Control Applications
Additional information
| Brand | Vitrek |
|---|
